Overview
TJ30 has a heritage upright lattice-matched structure and exhibits excellent radiation resistance. The average conversion efficiency exceeds 30% under AM0.
Design and Mechanical Data
Substrate Material：Ge
Base Material：GaInP/GaAs/Ge
AR-coating ：TiOx/Al2O3
Size：40.0mm×80.0mm，60.0mm×120.0mm，67.0mm×138.0mm
Thickness：180±20μm
Average Weight：≤110mg/cm2
Service orbit：LEO, MEO, GEO
Properties
Overview
- Name
- Enchampion Triple-Junction GaAs Solar Cells-TJ30
- Supplier
- Enchampion
- Type
- Solar Cell
- Flight proven
- Yes
- Flight proven mission(s)
- classified
